Speed (mm/min)
X Axis:
Y Axis:
Z Axis:
1800.000
1800.000
1500.000
Fig. 4-3 Modification page of “REFP Speed”
Press “Menu”→ 5. Mfr Param→ 5. REF. PointSet→ 1. REFP Speed, and press [OK] to enter the
page as Fig. 4-3. Then press “Up” and “Down” keys to select the axis speed parameter to be modified.
When the cursor is on an item, enter the new parameter value directly and then press [OK] to save it.
CAUTION
Note: If you switch to another parameter without saving the input value during parameter modification, this new
value will not be saved and the original value will be restored.
Selection of Parameter Value
Select the parameter value by directly pressing the “UP” or “Down” key. For example: the
modification method for the parameter “REFP Dir” is as follows.
Homing Direction
X Axis:
Y Axis:
Z Axis:
Negative
Positive
Positive
Fig. 4-4 Modification page of “REFP Dir”
Press “Menu”→ 5. Mfr Param→ 5. REF. PointSet→ 2. REFP Dir, and then press [OK] to enter the
page as shown in Fig. 4-4, and then press the “Up” and “Down” keys to select the axis direction
parameter to be modified. When the cursor is on an item, press the [OK] key to enter the interface as
shown in Fig. 4-5, the arrow indicating the current parameter value. Press [Up] or [Down] key to select
the desired parameter value, and then press the [OK] key to confirm the modification.
Direction of X
· Positive
Negative
4.4. System Start-up
Fig. 4-5 Selection dialog
The system interface is shown in Fig. 4-6 after power on. After the system is started, “Back to REF.
Functions & Operation Methods of Panel Keys「21」
    "
