6.3. Operations
The sub-menus under [Operations] are as shown in Fig. 6-4.
1. Back REF Point
2. Rect Machining
3. Select Line No
4. Machining Info
5. Park MCS Site
6. Select WCS
7. Array Process
8. Origin List
9. Nearby Process
All Home
Z Home
X Home
Y Home
1. Params Setting
2. Load the Last
1. Park Mode
2. Park Site
G54~G59 WCS
Fig. 6-4 Submenus under [Operations]
Press the “Menu” key→3. Operations, and then press [OK] to enter its page, in which select the
desired menu item by the “Up” or “Down” key. Fig. 6-5 is the [Operations] page.
1. Back REF Point
2. Rect Machining
3. Select Line No
4. Machining Info
6.3.1.
Fig. 6-5 [Operations] page
Back REF Point
For details, see Chapter 5.4.
6.3.2. Rect Machining
The system offers rectangle milling wizard; after setting parameters successfully, press the “Up”
and “Down” keys to select [Load Now], and then press [OK] to load the machining file; and then you
can press
to start machining.
You can also select “2. Load the Last”, and then press [OK] to load the last rectangle milling and
return to the machining page, and then press
to start machining.
Parameters “X Init” and “Y Init” decide the initial position of machining plane; “Height” and “Width”
decides the size of machining plane; two kinds of machining mode are available: “Horiz. Mill” (the feed
direction of tool is parallel to X axis) and “Long. Mill” (the feed direction of tool is parallel to Y axis);
