Parameter
Meaning
Setting range
Processing
Depth
It specifies the machining depth for 2D files.
-99999~0 mm
DXF parameters are for the translation of DXF files. In DXF file machining, the system treats the
action of tool lifting as the separate mark for the adjacent shapes, If there is no tool lifting, the
system will consider only one shape is being processed. If tool lifting occurs, it indicates the
machining of a complete shape is finished. For example, process several circles adjacent to each
other. The depth of each circle is 10mm, and each feed depth of Z axis is 2mm. If the parameter
“Shape Process” is set to “Yes”, the machine tool will process the current circle 5 times, and then lift
the tool, and then go to process the next circle. If it is set to “No”, the machine tool will process the
current circle once, then lift the tool, and then go to process the next circle. After all the circles are
processed once, this process will be re-executed 4 times to finish machining all the shapes.
ENG parameters are for the translation of ENG files.
PLT parameters are for the translation of PLT files. PLT is a format of 2D machining files defined by
an American company—Hewlett Packard (HP), usually used in embossment and advertising
carving. At the same time, PLT is also a kind of unit. Normally, 1plt=40.195mm, which can be
enlarged or diminished by setting the parameter “PLT Unit”.
Tool Change Parameters
Parameter
Tool Change
ATC Capacity
Current ToolNo.
Tool Offset
ToolChangeTip
X/Y/Z Cali Coor
CaliToolHeigh
Meaning
Setting range
Capacity of tool magazine
Tool No. currently used
Modification to the tool offset along each axis
Whether to send prompt when there is tool change
command in the file
The machine coordinate (X/Y/Z) of tool presetter in
fixed tool measurement
The required tool lifting height after the end of tool
measurement
1~20
1~Value of ATC
Capacity
X/Y/Z: -10000~10000
mm
Yes: Valid; No: Invalid
/
0.001~9999 mm
Ignore Command
Parameter
Ignore F Code
Ignore S Code
Meaning
Setting range
Yes: Enable the feed
Whether to enable the feedrate command in the
machining file
rate in the system
No: Enable the feed
rate in the machining
file
Whether to enable the spindle command in machining Yes: Enable the
file. When the parameter is set to “No”, speed spindle command in
Menu Page「47」
    "
