to the requirements of operation.
After backing to the reference point, the system will enter into the manual state automatically, the
screen display as shown in Fig. 5-10.
1X
0.000 Idle
1Y
0.000 SOff
1Z
0.000 Slow
Jog
100%
Fig. 5-10 Manual machining interface
CAUTION
Chapters 5.6, 5.7 and 5.8 are the machining operations of NK105G2, while Chapter 7 introduces the machining
operations of NK105G3 in details.
5.6.1. Mode Selection of Manual Machining
To satisfy the requirements of manual motion under different situations, this system provides two
kinds of manual motion modes: “Jog” and “Stepping”, which can be switched by pressing the “Shift”
key. The current motion mode is displayed at the bottom of the LCD.
Jog Motion Mode
There is no concrete data control under this mode. You can press an axis direction key (
,
,
,
,
,
) to move the machine tool accordingly under this mode. The
machine tool will not stop until the direction key is released. For the motion speed, it is decided by the
current type of speed (jog speed and rapid jog speed). This motion mode is suitable for coarse tuning
of the position of machine coordinate.
Stepping Motion Mode
Under this motion mode, the machine tool will move accordingly after an axis direction key (
,
,
,
,
,
position of machine coordinate.
) is pressed. This motion mode is suitable for fine tuning of the
Machine Tool Debugging「31」
    "
