Specialized Concentrated Focused
Silk-printed
name
GY06(YD+)
GY07(YP-)
GY08(YP+)
GY09(ZD-)
GY010(ZD+)
GY011(ZP-)
GY012(ZP+)
GY013(SP-)
GY014(SP+)
GY15(S_2)
GY16(S_1)
GY17(S_0)
GY18
GY19
GY20
+24V OUT
Corresponding signal
Remark
Positive differential signal of Y-axis direction
Negative differential signal of Y-axis pulse
Positive differential signal of Y-axis pulse
Negative differential signal of Z-axis direction
Positive differential signal of Z-axis direction
Negative differential signal of Z-axis pulse
Positive differential signal of Z-axis pulse
Spindle reverse rotation control port
Spindle forward rotation control port
2nd gear output port of spindle speed
1st gear output port of spindle speed
0th gear output port of spindle speed
Workpiece cooling output port
Spindle coolant output port
Auto lube output port
+24V output
YP+ and YP- are differential pair
signals of Y-axis pulse.
ZD+ and ZD- are differential pair
signals of Z axis direction.
ZP+ and ZP- are differential pair
signals of Z-axis pulse.
Multi-gear spindle speed control
ports: they can provide at most
8-gear speed control; in wiring,
COM at the inverter end needs
joining to the GND terminal.
For connection with +24V power
supply.
Silk-printed
name
GND
+24V IN
GX01(XORG)
GX02(XLM+)
GX03(XLM-)
GX04(YORG)
GX05(YLM+)
GX06(YLM-)
GX07(ZORG)
GX08(ZLM+)
GX09(ZLM-)
GX10
GX11
GX12
Table 2 Input signals
Corresponding signal
Remark
Power GND or COM port
+24V DC power input
Machine origin signal of X-axis
Positive limit signal of X-axis
Negative limit signal of X-axis
Machine origin signal of Y-axis
Positive limit signal of Y-axis
Negative limit signal of Y-axis
Machine origin signal of Z-axis
Positive limit signal of Z-axis
Negative limit signal of Z-axis
Reserved input
Reserved input
Reserved input
The two GND of the power terminal are
connected with power GND and the common
ground point of the machine tool respectively,
while GND of other terminals can be used as
COM signals.
For external connection with +24V DC power.
For external connection with mechanical,
photoelectric, or proximity switch, etc.
Wiring「7」
    "
