select “Update system” and then press [OK] to exit from system update page and enter the machining
page by booting the new system.
Export Backup
The software will be exported to the USB flash drive for backup, with its backup folder named
Backup.
Import Parameter
This menu item is used to import the parameter file (file name: Settings.dat) in the USB flash drive
into the system. Generally, the parameter file is under the root directory of the USB flash drive. If it is
not in the root directory, search for it in the Backup folder.
Version number
It is used to view the version number of BOOT loader.
6.7.4. Register
Move the cursor to “4. Register”, and then press [OK] to enter registration code input page, as
shown in Fig. 6-18.
Enter Reg. Code
ABCDEFGHIJKLMNOP
QRSTUVWXYZ
Fig. 6-18 Registration code input page
Register by entering the registration code in this page. Select a letter (end-around) by pressing
the “Up” and “Down” keys, and then press [OK] for conformation; for the input of a number, press the
corresponding number key.
6.7.5. Help
After the cursor is on the item “5. Help”, press [OK] to enter the “Help Message Show Delay”
parameter setting page as shown in Fig. 6-19. The value of this parameter is an integer within the
range of 1~999999.
Spec.: Help message
show delay
Value:
10
Unit: S
Fig. 6-19 Help setting page
Menu Page「59」
    "
