X soft limit
OK
ESC
Fig. 5-3 Soft limit prompt
Modification to this parameter becomes valid after system reboot.
5.3. Port Polarity
The polarities of input/ output ports in the software are specified in terms of the switch type: the
polarity of a normally closed switch is “P”; the polarity of a normally open switch is “N”. The
corresponding relation between system port No. and ports on the terminal board is as shown in Table 7
and Table 8.
The steps to modify port polarity are as following: press “Menu”→ 8. Diagnosis→ 2. Port List, and
then press [OK] to enter the interface as shown in Fig. 5-4. At this time, you can press the “Up” or
“Down” key to move the cursor to the desired port, and then press the “Shift” key to change its polarity.
After its polarity change, press [OK] to save the modification.
IN GX01
P
IN GX02 ○ N
IN GX03 ○ N
IN GX04 ○ N
System
port No.
0
1
2
3
4
5
6
7
8
9
A
B
C
D
Fig. 5-4 Modification interface of port polarity
Table 7 Corresponding signals of system input ports
Terminal
name
Corresponding signal
Remark
GX01(XORG) Machine origin signal of X axis
GX02(XLM+) Positive limit signal of X axis
GX03(XLM-) Negative limit signal of X axis
GX04(YORG) Machine origin signal of Y axis For external connection with
GX05(YLM+) Positive limit signal of Y axis
mechanical, photoelectrical or
GX06(YLM-) Negative limit signal of Y axis proximity switch.
GX07(ZORG) Machine origin signal of Z axis
GX08(ZLM+) Positive limit signal of Z axis
GX09(ZLM-) Negative limit signal of Z axis
GX10
Extended input
GX11
Extended input
GX12
Extended input
GX13
Extended input
GX14
Extended input
