Parameter
Meaning
Setting range
vibration will occur due to centrifugal force. The higher the speed is, the stronger the vibration will
be. Gradually increase the feed speed to see the state of vibration of the machine tool until the max.
circular speed is achieved, i.e. the max. speed of the machine tool without strong vibration. This
circle is regarded as the reference circle, and its max. speed is the max. speed of reference circle.
Max. centripetal acceleration “a” can be calculated in terms of the reference circle radius and its
max speed. The formula is as follows: V0 and R0 are the speed and radius of the reference circle
respectively, while Vx and Rx are the speed and radius of an arc to be processed. After Rx is
confirmed, when the arc machining speed is larger than Vx calculated, the system will limit the arc
machining speed automatically to ensure it is within the debugging value, i.e. the vibration will not
be stronger than that during ex-factory debugging.
a V02 Vx2
R0 Rx
Parameters Related with Machine Tool Debugging
Parameter
Meaning
Setting range
Axis OutpDir
The motion direction of each axis
Positive; Negative
MachineStroke
The valid motion stroke of a machine tool, i.e. the
Set according to the
valid machining range of a machine tool in X/Y/Z
actual machine tool
axis
Upper limit setting
range:
lower
The upper and lower limit of machine coordinates of limit~67108.864;
ChangeToolStroke
X/Y/Z axes in changing tool.
Lower limit setting
range:
-67108.864~67104.864.
The worktable stoke per pulse sent by the CNC
Pulse Equiv.
device or the rotary degree of a rotary axis, i.e. the 0.00009~999.0 mm/p
least distance the CNC system can control
REF. PointSet
REFP Speed
The speed of rough positioning in backing to 0.001~Max. speed of
machine origin
machine tool
REFP Dir
The direction of rough positioning in backing to
Positive; Negative
machine origin
The additional motion distance after fine positioning
Retract Dist
stage in backing to machine origin, to move out of 0~10000 mm
the machine origin signal sensitive zone
Sign of BK REF
Whether to eliminate the sign of backing to machine Yes: Eliminate
origin after E-stop
No: Not eliminate
