Manual Set
Manually move the tool onto a certain height, press
+
to open the tool measurement
page. Selecting the menu item “Manual Set” can set the current Z machine coordinate to the current
tool offset of Z axis.
Single Measure
Single tool measurement. Manually move the spindle/tool onto a position above the fixed tool
sensor (also called tool presetter), and select “Single Measure” in the measuring page. The system will
conduct measuring process automatically and set the measuring result to the current tool offset of Z
axis.
All Measure
Namely, measuring tools one by one. Like single measuring, manually move the spindle/tool onto
a position above the fixed tool sensor and select “All Measure” item. The system will conduct
measuring process automatically and set the result to the current tool offset of Z axis. Please note that
measuring process of “All Measure” differs because of different cylinder configuration.
For Dual-cylinder Configuration
If the current tool (the tool in the spindle) is T1, the measuring sequence is T1-T2; if the current
tool is T2, the measuring sequence will be T2-T1.
For Three-cylinder Configuration
If the current tool is T1, the measuring sequence is T1-T2-T3; if the current tool is T2, the
measuring sequence is T2-T3-T1; if the current tool is T3, the measuring sequence is T3-T2-T1.
CAUTION
“Manual Set” “Single Measure” and “All Measure” are effective on condition that the current tool is single tool,
or tool number being 1 or 2 or 3.
8.1.6. Breakpoint Resume
After breakpoint resume or power-off resume is executed, the system will open the corresponding
cylinder according to the tool No. before machining stops, and start the spindle after 200ms delay.
「74」Cylinder ATC and Linear ATC Function
    "
