Parameters Related with Machining
Parameter
Meaning
Setting range
Back REF First
Whether homing all the axes before machining Yes: Required
required or not
No: Not required
Lifts on Pause Lifting amount at pause
0~10000 mm
G73_G83Retract Retract or spacing amount of G73_G83 command 0~1000000 mm
Ratio ON Manu Manual Feedrate affected by override
Yes: Affected
No: Not affected
CycleProcess
Cycle Process Whether to enable cycle process
Yes: Enabled
No: Disabled
Cycle Times
Cycle machining times, valid when “Cycle Process” is
1~9999
set to “Yes”
Cycle Interval
Interval between two adjacent cycles
0~3600000
S_Off in Intev
Whether to stop spindle in the interval
Yes: Stop
No: Not stop
G73_G83Retract Retract or spacing amount of G73_G83 command 0~1000000 mm
Homing all the axes before machining can prevent machining deviation and ensure position
accuracy. It is recommended to set “Back REF First” to “Yes” to disable a machine tool to run
automatically if backing to machine origin is not executed before machining. When the home switch
cannot work normally, “Back REF First” can be set to “No”.
G73_G83Retract: the retract amount after each feed under G73 command; under G83 command,
the distance between the feed plane where the cutter changes from G00 to Gxx and the previous
peck depth.
Parameters Related with Offset
Parameter
Meaning
Setting range
PublicOffset
Aiming at all the WCSs, used for adjusting workpiece
-10000~10000 mm
origin of X, Y and Z axes
Work Offset
D-value of WCS origin and MCS origin
-10000~10000 mm
The relation of workpiece offset, tool offset and public offset is as following:
Workpiece coordinate = Machine coordinate - Workpiece offset – Tool offset – Public offset
Spindle Parameters
Parameter
SpindleStop
SOff at pause
SOff at Stop
SOff at End
ProcessEndTip
Meaning
Setting range
Whether to stop spindle at pause
Yes: Stop; No: Not stop
Whether to stop spindle at stop
Yes: Stop; No: Not stop
Whether to stop spindle when machining completed Yes: Stop; No: Not stop
Whether to turn on the red light indicator as a sign of
Yes: On; No: Off
the completion of machining
