Specialized Concentrated Focused
+
or
+
. 1S represents the 1st-gear rotary speed, 2S the 2nd-gear rotary
speed, and nS the nth-gear rotary speed.
CAUTION
For NK105G3, in idle state, spindle is turned ON or OFF by pressing
increased or decreased by pressing
+
- or
-
+ - ..
; in machining state, spindle gear is
Type of Manual Speed
Manual speed is divided into two types: rapid jog speed (High) and jog speed (Slow), which are
switched by pressing
0 . Refer to Chapter 5.6.2 for the speed setting method.
CAUTION
For NK105G3, rapid jog speed and jog speed are switched by pressing
5.
Menu Page
Press
to enter the menu page. There are altogether 8 parameter items in the menu but
the LCD can only show 4 of them at a time, as shown in Fig. 6-2.
1. Local Files
2. USB Files
3. Operations
4. Oper Param
Fig. 6-2 Menu page
Press “Up” and “Down” keys to select the desired item and then press [OK] to enter the
corresponding sub-menu.
Menu Page「39」
    "
