Select the type of trigger for image acquisition.
Frame Burst Start
The trigger for starting the capture of the bursts of frames in an acquisition.
A burst of frame(s) is defined as the capture of a group of one or many frame(s)
within an acquisition
Trigger Mode
Controls if the selected trigger is active.
Off
Disable the selected trigger.
On
Enable the selected trigger.
Trigger Source
Specify the internal signal or physical input Line as the trigger source.
Software
Specify that the trigger source will be generated by the software when you execute the
TriggerSoftware command or set Enable Auto Trigger switch to on.
Line 0, Line 1, Line 2 ...
Specify the selected physical line (or pin) and associated I/O control block as the
external source for the trigger signal.
Counter 0
Specify the selected Counter signal as the internal source for the trigger.
Action 1
Specify the selected Action Command as the internal source for the trigger.
Note
For details about Action Command, see GigE Vision Action Command.
Anyway
All the above-mentioned trigger source types (Software, Line 0, Line 1, Line 2 ...,
Counter 0, and Action 1will be used as the source for the trigger.
Trigger Activation
Specify which signal transition activates the trigger.
Note
Trigger Activation is only available when Trigger Source is set to Line 0, Line 1, Line 2 ...,
Counter 0, or Anyway.
