Note
If you increase the packet size above 1,500 bytes, make sure that Jumbo Frame of the
network adapter is enabled.
Gev SCPD
Specify the delay (in timestamp counter units) to insert between each packet for this
stream channel. This can be used as a flow-control mechanism if the application or the
network infrastructure cannot keep up with the packets coming from the device.
Note
Increasing the delay may reduce the amount of dropped packets at the expense of
slowing the data transmission. As a result, the camera's frame rate may decrease.
GEV PAUSE Frame Reception
Controls whether incoming PAUSE Frames are handled on the given logical link.
GEV Stream Channel Selector
Selects the stream channel to control.
LinkConfiguration
Bootstrap register ConnectionConfig.
LinkConfigurationPreferred
Bootstrap register ConnectionConfigDefault.
Cl Configuration
Select a channel mode for the camera. The image outputting way varies according to
different channel mode.
5.3 Trigger
On the Trigger tab, you can configure features related to the trigger of IO input and IO
output.
5.3.1 IO Input
On the Trigger tab, the IO Input section displays trigger related parameters, which can be
used to control the acquisition of images.
Note
The features vary with different camera models.
Trigger Selector
