Hikrobot Machine Vision Software User Manual
The following table briefly introduces the description of each feature category.
Table 5-2 Feature Category Description
Feature Category
Description
Contains the features related to the control and information of
the camera.
Device Control
You can do the followings:
● View the camera details including device type, version,
manufacturer details, device ID, device temperature, etc.
● Modify the alias and reset the camera.
Image Format Control
Contains the features related to the format of the transmitted
image.
You can do the followings:
● View the live view image width and height, pixel size, etc.
● Set ROI, modify pixel format, set image reverse, test pattern,
and set the embedded information, etc.
Acquisition Control
Analog Control
LUT Control
Digital I/O Control
Action Control
Contains the features related to image acquisition, including
trigger and exposure control.
You can set the trigger mode, trigger source, acquisition mode,
etc.
Contains the features related to the video signal conditioning
in the analog domain.
You can adjust the analog signal including analog gain, black
level, brightness, gamma, sharpness, AOI, etc.
Contains the features related to the look-up table (LUT)
control.
You can view the user look-up table and set the LUT index and
value.
Contains the features related to the control of the input and
output pins of the camera.
You can manage the digital input and output.
Contains the features related to the control of action
command.
You can use the features to define the mechanism of the
action command.
51
