Hikrobot Machine Vision Software User Manual
Local encoding type refers to the encoding type of the current PC where the Software
runs. UTF-8 is a method for encoding Unicode characters using 8-bit sequences.
Bayer Interpolation
The interpolating modes for transferring an image of bayer format to RGB format.
cti Default Path
cti file is used for GenTL management. You can set a default path for cti file. If you have
configured and enabled the default path of cti file, the Software will load it automatically
once you start the Software. See GenTL Management for details about GenTL
management.
Temperature Screening Settings
Normal Region Color
The color or regions with normal temperature.
Alarm Region Color 1/2
The two colors of regions with an alarm triggered by abnormal temperatures.
Note
● If the alarm of screening region is not acknowledged after 200 seconds, the two
colors will flash by turns.
● To display the colors of screening regions, you need to finish the following
operations beforehand.
○ Draw a temperature screening region. See Temperature Screening Configuration.
○ Set alarm rules of temperature screening regions. See Configure Temperature
Screening Parameters.
○ Select Region Information Overlap as Client.
Output Logs
Logs about temperature screening can be output if you enable this.
3.3.2 Capture and Recording Settings
You can set the recording parameters and capture parameters as required.
Note
For details about capture and recording, see Capture and Recording.
Go to Settings → Recording/Capture to configure the following parameters.
Select Directory
Select Directory for the captured pictures and recorded videos.
Saving Path
