Hikrobot Machine Vision Software User Manual
File Name
MvProducerGEV.cti
MvProducerU3V.cti
MvProducerVIR.cti
Device Type
Camera with GEV interface.
Camera with USB interface.
Virtual camera.
● The Software also supports third-party cti files which conform to the GenTL standard.
● For third-party cti files, you need to get them by yourself. You can contact the
corresponding manufacturer for support.
● If you have configured the default path of cti file, the Software will load it
automatically once you start the Software. See General Settings for details about how
to set the default path of cti file.
The device list will enumerate the cameras that can be discovered by the cti file.
Note
CoaXPress cameras can only be connected by GenTL. If connected, you can control the
camera and acquire image data.
3. Optional: Connect the frame grabber, and then click to refresh cameras after loading
the cti file.
Different icons indicate different status of a frame grabber.
Table 4-6 Frame Grabber Status
Icon
Status
Description
Available
The frame grabber can be connected and
operated.
Connected
The Software has been connected to the frame
grabber. You can configure parameters of the
frame grabber and enumerate cameras connected
to the frame grabber.
The cameras connected to the enumerated frame grabber will be displayed. You can
double-click a camera to connect to it.
4. Optional: Perform the following operations.
● For CameraLink frame grabbers which cannot enumerate real cameras, right-click a
frame grabber and select Open as a Virtual Camera to connect and operate the
cameras of the frame grabber as virtual cameras.
● After connecting to the frame grabber, the feature tree of the frame grabber will be
displayed on the right. Configure the features if necessary.
● After connecting to the frame grabber, right-click it and then select Save GenlCam
XML to save the frame grabber's GenlCam file to the PC in XML format.
