Hikrobot Machine Vision Software User Manual
Balance White Auto
Set the mode for automatic white balancing between the color channels. Once set, the
white balancing ratios are automatically adjusted.
Off
Set white balancing manually using Balance Ratio Selector and Balance Ratio.
Once
White balancing is automatically adjusted once by the camera. Once it has converged,
it automatically returns to the Off state.
Continuous
White balancing is constantly automatically adjusted by the camera.
Balance Ratio Selector
Selects which Balance ratio to control.
Red
Balance Ratio will be applied to the red channel.
Green
Balance Ratio will be applied to the green channel.
Blue
Balance Ratio will be applied to the blue channel.
Balance Ratio
Set the weight value (0 to 4095) for the channel selected from Balance Ratio Selector.
5.2.3 Transport Layer Control
The Transport Layer Control feature allows you to configure parameters related to data
packet transmission.
Note
The available features and parameters vary with different camera models. Here we only
introduce part of the features and parameters.
GEV SCPS Packet Size
Specify the maximum size (unit: byte) of a data packet transmitted via Ethernet. The
larger the packet size, the less the Ethernet overhead load and hence the higher the
network efficiency.
The default value (1,500 bytes), which is also the recommended value, is sufficient for
most configurations.
59
    "
