Hikrobot Machine Vision Software User Manual
Locate Cross Line
to the
Image/Window
Center
Right-click , and then click Central to locate the cross line to
the center of the image or display window.
6.8 Configure Grid
You can configure grids on the image when acquiring image data in 1-window mode. This
is especially helpful when you need to align objects on the image.
Steps
1. Connect a camera and then start acquisition in 1-window mode.
Note
For details about image acquisition in 1-window mode, see Acquisition and Live View in
1-Window Mode.
2. Click to display grids on the image.
93
    "
