Hikrobot Machine Vision Software User Manual
8.2.2 Configure Logs
Configure log settings of cameras and frame grabbers.
Camera Logs
Select Camera in LogSource, and you can click More on the top of the log viewer window to
configure log view settings and log service settings of cameras.
Log View Settings
You can set the DLL(s) to be displayed on Log Viewer.
Select DLL(s)
Check the checkbox(es) to select DLL(s). You can only select MvCameraControl.dll,
MVGigEVisionSDK.dll, MvUsb3vTL.dll, and MvCamLVision.dll.
MvCameraControl
MVGigEVisionSDK
MvUsb3vTL
MvCamLVision
Logs about operations on the Software will
be displayed (if exist).
Logs about the Software accessing USB3
Vision cameras will be displayed (if exist).
Logs about the Software accessing USB3
Vision cameras will be displayed (if exist).
Logs about the Software accessing
Camera Link cameras will be displayed (if
exist).
Add DLL(s)
Enter the name of a DLL in the input box, and then click Add.
Max. Displayed Logs
Set the maximum number of displayed logs.
Note
The range of maximum displayed logs is from 1 to 100,000 (default value: 1000).
Interval for Update (ms)
Set the time interval (unit: ms) for upgrading the log list.
Note
The range of the time interval is from 100 to 1000,000 (default value: 1000).
Log Service Settings
Max. Storage Size
137
