Hikrobot Machine Vision Software User Manual
4.2.3 Other Features
Other features are provided for the USB3 Vision cameras on the device list, including U3V
Transfer settings, device user ID settings, GenICam XML settings, etc.
U3V Transfer Settings
You can edit the packet size and streaming channels for a USB3 Vision camera.
Right-click a USB3 Vision camera and then click U3V Transfer Setting to open the U3V
Transfer setting window, and then configure Packet Size (value range: 64 to 20,480 KB,
default value: 1024 KB) and Streaming Channel(s) (value range: 1 to 10, default value: 8)
according to the performance of the USB frame grabber. The lower the performance of the
USB frame grabber, the smaller the Packet Size and the more Streaming Channel(s) you
should set so as to alleviate data transmission between and camera and the Software.
Note
U3V transfer settings is only available when the camera is connected or in acquisition.
Save GemICam XML
Right-click a USB3 Vision camera, and then click Save GemICam XML to save the camera
information as XML file for secondary development of the Software.
Note
Saving GemICame XML is only available when the camera is connected or in acquisition.
Rename User ID
Right-click a USB3 Vision camera, and then click Rename User ID to edit user ID of the
camera.
Note
Renaming user ID is only available when the camera is connected or in acquisition.
Stick Camera to Top
Right-click a USB3 Vision camera and then click Stick to Top to stick the camera to the top
of the USB3 Vision camera list.
If you want to cancel sticking the camera to the top, right-click the camera and then click
Cancel Sticking to Top.
4.3 Camera Link Camera Management
Camera Link camera is the camera using Camera Link standard for data transmission.
After adding Camera Link cameras to the Software, you can do further operations such as
