550℃.
Target Distance
Set the linear distance from the target object to be measured to the device (unit: m).
Full Screen Emissivity
Set the emissivity of the target object. The emissivity value varies for different objects.
Refer to the user manual of the corresponding camera model for details.
Temp Measurement Expert Mode
When enabled, you can set the corresponding parameters for each temperature
screening region respectively.
Expert Mode
Temp Region Reflect Enable
Set whether to enable reflection for the temperature screening region when there is a
high-temperature object at the scene, and a measured object with low emissivity
reflects the high-temperature object.
Temp Region Reflectance
Set the reflectance value of the temperature screening region, which needs to be
consistent with the temperature value of the high-temperature object.
Temp Region Target Distance (m)
Set the linear distance from the target object to be measured to the device (unit: m).
Temp Region Emissivity
Set the emissivity value of the target object (unit: %). The emissivity value varies for
different objects. Refer to the user manual of the corresponding camera model for
details.
Alarm
Under Alarm, you can configure parameters related to the temperature triggered alarms for
a single region or of comparing two regions.
Single Region Alarm
Set the alarm rule for a single temperature screening region you have drawn.
Point
For point ROIs, you can set the following parameters for conditions to trigger or
restore alarms.
Point Temp
Select > or < from the drop-down list, and enter a temperature value correspondingly
to set the alarm rule.
E.g., If you select > and enter 50 in the box, an alarm will be triggered when the
screened temperature exceeds 50°C.
