Hikrobot Machine Vision Software User Manual
Feature Category
Description
User Set1, User Set2, User Set3
The user sets that can be used to load and save your own
camera settings.
Initially, these user sets contain the same parameter
values as the Default user set. You can save one of them
to overwrite those values with your own settings to create
a user set that is customized for your usage scenario. See
the description of User Set Save below for details about
saving User Set.
User Set Load
Load the User Set specified by User Set Selector to the
camera and make the it active. When a user set is loaded, it
overwrites the current camera settings.
Note
● Loading a user set is only possible when the camera is
idle, i.e., not acquiring images.
● Except for the Default user set, you should have saved a
User Set before you can load it. See the description of
User Set Save below for details about saving User Set.
User Set Save
Save your own camera settings as the User Set specified by
User Set Selector.
Note
● Only the UserSet1, UserSet2, and UserSet3 can be saved.
The other user sets are read-only.
● Saving a user set is only possible when the camera is idle,
i.e., not acquiring images.
User Set Default
Select User Set to automatically load and make it active by
default when the camera is reset to its power up state.
5.2 Common Features
On the Common Features tab, you can configure the features which are frequently used in
camera configuration, including basic features (Acquisition Frame Rate Control Enable,
53
