Hikrobot Machine Vision Software User Manual
Operation
Description
Select Color Channel
for Display
If the camera is a color camera, you can check the
checkbox(es) in the table, the selected color channel's real-time
distribution will be displayed on the histogram.
Export Histogram Data Click Export to export the histogram data to the local PC.
Restore X
Click Restore X to restore the coordinates if you have zoomed
the histogram.
6.12 Temperature Screening Configuration
For infrared cameras, you can perform temperature screening configurations, such as
drawing different types of temperature screening regions and configuring the relevant
parameters, including those related to screening, alarm, and display.
6.12.1 Draw a Region for Temperature Screening
To perform temperature screening configurations, you need to first draw regions for
temperature screening.
Before You Start
Make sure you have connected an infrared camera to the Software.
Steps
1. Start the live view of the camera.
Note
Refer to Acquisition and Live View in 1-Window Mode and Acquisition and Live View in
Multiple-Window Mode for details.
2. Click above the live view window.
102
