Hikrobot Machine Vision Software User Manual
Feature Category
Counter and Timer
Control
File Access Control
Event Control
Chunk Data Control
Transport Layer
Control
User Set Control
Description
Contains the features related to the usage of programmable
counters and timers.
You can set the counter and timer, which count the triggering
signal and control the exposure according to your needs.
Contains the features related to accessing files in the camera.
You can use File Access to export and import camera settings.
Contains the features related to the generation of event
notifications by the camera.
You can use Event Monitor to view the messaging channel
events to determine causes of issues that may occur during
the use of your camera.
Contains the features related to the generation of
supplementary image data (i.e., Chunk data) and the
appending of that data to every image that you acquire.
You can enable chunk data, and set the content of the chunk
data.
Contains the features related to the control of transport layer.
You can set the parameters of transport layer of the camera.
Contains the features related to the global control of camera
settings.
User Set Current
The currently loaded user set.
● "0" represents Default, i.e., the factory settings.
● "1" represents UserSet1.
● "2" represents UserSet2.
● "3" represents UserSet3.
User Set Selector
Select User Set.
Note
The number of User Sets vary with different camera models.
Default
The read-only factory settings. In other words, the default
startup settings on the camera.
