Hikrobot Machine Vision Software User Manual
● Select Camera Link, and the devices connected to the camera link will be displayed
on the right.
● Select an interface under Camera Link, and the cameras connected to the camera
link will be displayed on the right.
● The tool will not auto refresh the devices connected to camera link by default. You
need to click on the right of Camera Link to manually enumerate the cameras.
GenTL Interfaces
Right-click GenTL and click Select CTI File. Select and open a CTI file, and the tool will
enumerate the frame grabbers and cameras in the CTI file.
● Select GentTL, and all the frame grabbers in the CTI file will be displayed on the
right.
● Select a frame grabber under GentTL, and the cameras connected to the frame
grabber will be displayed on the right.
● Select a camera under GentTL, and the cameras connected to all the frame
grabbers will be displayed on the right.
● The tool will not auto refresh the frame grabbers and cameras connected by the
GenTL by default. You need to click on the right of GenTL to manually
enumerate the cameras.
3. Optional: Click to select the to-be-displayed device information (model name, MAC
address, firmware version, etc.).
4. Select cameras or frame grabbers to be updated.
Note
No more than 20 cameras or frame grabbers can be selected.
5. Click to select an update file (DAV format) in the local PC.
The matched cameras will be selected automatically.
6. Click Update.
Note
● During the update, do not break the connection between the devices and the PC, and
ensure that the devices are working.
● The devices will restart automatically upon finishing the update.
● The update of frame grabbers will take effect after restarting the PC.
