3）Halftoning Type
Select halftone dots according to different application scenarios, commonly used are 2BIT_LMPCS and 2BIT_KMPCS_UV.
2BIT_LMPCS ： The dots are finer, but it is more sensitive to ink, and the transition is difficult to adjust (the transition
problem can be optimized by setting to turn off the midpoint).
2BIT_KMPCS_UV ： The color patches are uniform, the printed color is rich, and the transition is smooth (often used in
8-color light black schemes).
4）Setting
[Dot Dilution] is used to dilute or deepen the overall color concentration, and it is used when the overall ink volume is too
thick or too light. The default value of the slider is 2.5 (default dilution value). The larger the dot dilution value is than 2.5,
the more dilution is indicated, and vice versa.
[Advanced Settings] is only used for variable dot nozzles and generally does not need to be adjusted. It is recommended to
use the default parameters and is used when obvious step changes cannot be corrected.
When the transition of LMPCS and MMH dots is not good, you can uncheck Dot2 (the mode of turning off the midpoint) in
the advanced settings to adjust the transition problem.
In the mode interface, for multi-head Hosonsoft board models (more than three heads), for precision optimization, the MMH
series dots need to select the corresponding nozzle combination mode of the machine (ECO indicates a photo machine, and
SUB indicates a paper printer). You can [Print Reference Image] to confirm whether the adjusted dot parameters are
reasonable.
Click "Confirm" to exit the parameter setting after the parameters are set.
5）Calibration Mode
Linearization：Prints ink colors and does not participate in other colors.
ICC：Prints to restore screen colors.
ICC（Vivid mode）：When printing RGB format images, if you need to ensure the vividness after enabling ICC, you can
select the curve of ICC (Vivid mode) on the print confirmation interface for printing.
Iterative Color Matching：Used when the color matching target has an icc.
Express Color Matching：Used when the color matching target is linearized.
2. Ink Limit
After completing the parameter settings of the curve, click Next to enter the monochrome ink cutoff interface, as shown in the
following figure:
Operate according to the prompts of steps 1, 2, and 3 on the interface.
