the following text.
It is used to draw barcodes in the canvas.
Click the icon in the toolbar, place the mouse on the canvas and drag it to draw
Draw Static Barcode the barcode. Double-click the barcode, and then select the barcode type you
need to use and set the variable rules in the barcode property interface. The
specific usage will be introduced in the advanced functions section.
3. Information Prompt Area
This area will provide you with various real-time information about the current software, such as the functions of menu and
toolbar buttons, the currently default printer, the printing status, the number of images on the canvas, the image names, as well as
the current position of the cursor, the scale of the ruler, etc.
Prompt message
Details
View the default printer
The name of the default printer of the current system is displayed at the bottom of the main
interface of the software.
The status of the printer is displayed at the bottom of the main interface of the software.
Printer status
If the current default printer is idle, it will show "Ready". If the current default printer is
printing, it will display "Printing" and also show the printing progress.
The number of graphic
elements in the canvas
The number of graphic elements on the canvas is displayed in real time at the bottom of the
main interface of the software. These graphic elements include self-drawn vector graphics
and imported color images.
Show the name of the When a graphic element on the canvas is selected, the name of the graphic element will be
graphic element
displayed in the area at the bottom of the main interface of the software.
When you move the mouse on the canvas, the coordinate position of the mouse on the
Show the coordinate
canvas will be displayed in real time in the area at the bottom of the main interface of the
position of the mouse
software.
4. Layout Toolbar
When there are images on the canvas, you may need to perform layout operations on the canvas images to output the images in
the most material-saving way.
Icon
Function
Function Details
Most saving
material
Automatically typeset all graphic elements in the most material-saving way,
and supports setting the horizontal and vertical spacing between graphic
elements and canvas spacing.
Align left
Center left and
right
Align right
Align the other images in the selected image to the left with the image at the
leftmost boundary.
Align the midlines of the other images in the selected image with the midline
of the image at the leftmost boundary.
Align the other images in the selected image to the right with the image at the
rightmost boundary.
11
