GigE Area Scan Camera User Manual
Second Type of 12-Pin P10 Connector Definition
The second type of 12-pin P10 connector definition is shown below.
Note
Refer to the table below and the label attached to the power and I/O cable to wire the
device.
No.
1
2
3
4
5
6
7
8
9
10
11
12
Table 4-3 Second Type of 12-Pin P10 Connector Definition
Signal
I/O Signal Source
Description
GND
Line 2-
Device power supply ground
DC_PWR
--
Device power supply
DC_PWR
--
Device power supply
OPT_IN-
Line 0-
Opto-isolated input signal ground
OPT_OUT-
Line 1-
Opto-isolated output signal ground
GND
--
Device power supply ground
GND
--
Device power supply ground
232_RXD
--
RS-232 receives
232_TXD
--
RS-232 transmits
GPIO2
Line 2+
Input or output
OPT_OUT+
Line 1+
Opto-isolated output
OPT_IN+
Line 0+
Opto-isolated input
4.2 Indicator
The device’s indicator is used to indicate the operation status of the device.
Note
● The indicator status may differ by device models, and actual devices you purchased
shall prevail.
● When the indicator is flashing rapidly, flashing slowly, or flashing very slowly, its unlit
interval is 0.2 sec, 1 sec, and 2 sec respectively.
● The indicator sometimes may show a purple color when red and blue colors flashing at
the same time.
