Summary of camera modes 115
Line scan cameras
Camera Modes
Connections
Continuous line scan rate mode:
• Line scan rate determined by the frequency of
the hsync signal.
Variable line scan rate mode:
Y • Line scan rate determined by time between
external trigger pulses.
• Internal or external exposure time control.
R Fixed line scan rate with frame trigger mode:
• Line scan rate determined by time between
A 5 external trigger pulses.
• Internal or external exposure time control.
IN 0 Variable line scan rate with frame trigger mode:
0 • Line scan rate determined by time between
external trigger pulses
IM 2 • Internal or external exposure time control.
Fixed line scan rate with variable frame size:
• Line scan rate determined by time between
L Y external trigger pulses.
• Internal or external exposure time control.
E A Variable line scan rate with variable frame size:
• Line scan rate determined by time between
external trigger pulses.
PR19 M • Internal or external exposure time control.
• Video and synchronization signals between
camera and frame grabber (synchronization
signals can be provided by the frame grabber).
• Video, synchronization and exposure (trigger)
signals connected between camera and frame
grabber.
• External trigger signal connected to frame
grabber.
• Video, synchronization, and exposure (trigger)
signals connected between camera and frame
grabber.
• External line and frame trigger signals connected
to frame grabber.
• Video, synchronization, and exposure (trigger)
signals connected between camera and frame
grabber.
• External line and frame trigger signals connected
to frame grabber.
• Video, synchronization, and exposure (trigger)
signals connected between camera and frame
grabber.
• External line and frame trigger signals connected
to frame grabber.
• Video, synchronization, and exposure (trigger)
signals connected between camera and frame
grabber.
• External line and frame trigger signals connected
to frame grabber.
    "
