Operation Manual of WEICHAI GENSET
7320MKII
Alarm
When an alarm is valid, the internal audible alarm will blow, and if defined, the LED
indicator on the right side of the screen will be on mute: This alarm can be activated
by pressing the mute/lamp test button .
The LCD display skips from the "current page" to the alarm page.
1/2 Alarm
Low oil pressure
Common alarm
Number of alarms. The first of the two
alarms currently displayed
Cause of alarm, such as low oil pressure
Type of alarm, such as common
alarm
LCD can display multiple alarms, such as "high coolant temperature", "emergency
shutdown" and "low cooling temperature alarm". These will be displayed
automatically in the order in which the alarm occurs, or manually turned by pressing
the up or down button
.
If an alarm occurs, the LCD screen displays the specific text information. If an external
alarm occurs later, the controller will display text information.
such as:
1/2 Alarm
Low oil pressure
2/2 Alarm
High coolant temperature
Common alarm
Shutdown alarms
44
    "
