Operation Manual of WEICHAI GENSET
switchover to let the set run with load ('generator set closing' and delay load
outputs 1, 2, 3 & 4 will be valid (if defined)). When the remote start signal is
released, the set still runs with load until the Stop/Reset button
or
AUTO mode button is pressed.
Test mode (only applicable to DSE6020 MKII)
This button indicates that the controller gets into the test mode
. Once
the controller gets into the test mode , you press the button
the generator set will be started and run without load.
, and
Once the set is started, it will run with load automatically ('generator set
closing' and delay loads 1, 2, 3&4 will be outputted in the sequence from low
to high (if defined)).
AUTO mode
This button indicates that the controller gets into the AUTO mode . In this
mode, the controller can automatically control the set. The controller will
monitor the remote start input, and the set will automatically start with load
once the start request is sent ('generator set closing' and delay loads 1, 2,
3&4 will be outputted in the sequence from low to high (if defined)).
When the start signal is released, the controller will automatically unload the
set. The set will be shut down after the signal passes through the delay timer
and the cooling timer ('generator set closing' and delay load outputs 1, 2, 3&4
will be valid (if defined)). The controller will wait for the next start signal.
Alarm mute/indicator test
This button will mute the alarm buzzer (if defined) and will be used to turn
on all the indicators on the panel.
Start
This button is only valid in the Stop/Reset mode
, manual mode
and test mode .
In the stop/reset mode , press the start button , and ECU will be
powered on but the engine will not be started. It can be used to check the
14
