status of CAN communication and the fuel system.
In the manual mode or test mode , press the start button , and
the generator set will be started. It will run without load in the manual mode
or run with load in the test mode .
Icon
Description
Menu navigation button
It is used to check meter parameters, event records and the user-defined
interface.
For more information, refer to the "Operation" section of this manual.
Switchover to generator set
This button is only valid in the manual mode , which allows the load to be
switched to the generator set.
Alternator opening (only applicable to DSE6010 MKII)
This button is only valid in the manual mode , which allows the operator
to open the alternator switch and remove the load.
Switchover to mains supply (only applicable to DSE6020 MKII)
This button is only valid in the manual mode
to switch over the load to mains supply.
, which allows the operator
Meter icon
Icon Description
/ Voltages of set and mains supply that will be displayed on the home page by default
(only applicable to DSE6020MKII)
Voltage and frequency of set
Voltage and frequency of mains supply (DSE6020 MKII only)
Current of set
Current of mains supply (only applicable to DSE6020 MKII, when the current
transformer is on the load side)
Load power
Engine speed
Operating hours
