Operation Manual of WEICHAI GENSET
Shutdown alarm icon
The fault must be removed before restart. If the alarm condition is present, the
controller will not restart (except for low oil pressure alarm and similar safety alarm,
because the oil pressure is very low when the engine is in standby state).
The alternator will be locked and stopped immediately after the shutdown alarm is
given. When the shutdown becomes valid, the controller will cut off all delay load
outputs and turn off the alternator output to remove the load. Once this condition
happens, the controller will immediately stop all sets from operating, to prevent this
condition from worsening. The controller can only be restarted after the reception and
release of the alarm and removal of the fault.
As the alarm will be locked by shutdown, to remove the fault, please press the
Stop/Reset button.
Icon Fault
Description
User-defined input
The controller detects that the user-defined input set by
the user as a fault has become valid.
Analog input
The controller detects that the input set by the user as
a fault has become valid.
Start failure
The engine fails to start.
Low oil pressure
The controller detects that the engine oil pressure is
lower than the preset alarm value
The
engine
overheats.
The controller detects that the engine coolant
temperature is higher than the preset high temperature
alarm value
Underspeed
The engine speed is lower than the preset minimum
value
Excessively high The engine speed is higher than the preset high alarm
speed
value
Charging failure
At the W/L terminal, it is detected that the voltage of
auxiliary charging motor is low
Low oil level
The oil level sensor detects that the oil level value is
lower than the preset low level alarm value
High oil level
The oil level sensor detects that the oil level value is
higher than the preset high level alarm value
Alternator
undervoltage
The alternator output voltage is lower than the preset
alarm value
Alternator over- The alternator output voltage is higher than the preset
voltage
alarm value
