Operation Manual of WEICHAI GENSET
Mode icon
An icon will pop up in the mode icon area to indicate the mode currently used by the
controller.
Icon
Notes:
The engine is in standby state and the controller is in the Stop/Reset
mode
The engine is in standby state and the controller is in the manual mode
The engine is in standby state and the controller is in the test mode
The engine is in standby state and the controller is in the AUTO mode
When the timer starts working, the icon for the preset turning time,
waiting time for turning, etc. will pop up
It pops up when the engine is running with/without load and all timers
have finished timing
When the engine is idling, the speed for the icon to pop up will become
slow
It pops up when FPE is started
It pops up when the controller is connected to the USB equipment
It pops up when the configuration file or engine file is damaged
Common alarm icon
Giving a common alarm generally indicates that the condition is not very serious, and
will also not affect the operation of the alternator system. It is just to remind the user
that there is a poor condition.
By default, the common alarm will automatically disappear after the fault is removed.
If all the common alarms are set to be locked and saved, these alarms can be released
only after manual reset. The controller can be connected to the computer and be set
through DSE settings.
