points in the original shape array, and even if
the starting point positions are modified later,
this distance will not be affected;
Note: If the parameters are not set properly,
such as less than the spacing between adjacent
trajectories (the distance between start points),
these two trajectories cannot be connected by
a straight scan line.
11. ring cutting
Because the corner of the part is easy to damage, which will affect the quality of
the whole part, in order to effectively avoid the damage of the part, you can define the
size of "surrounding cutting corner" in the cutting parameters, and add the
corresponding surrounding structure outside the contour corner.
After selecting the figure, click the "ring cutting" button in the process column to
obtain a better sharp corner cutting effect.
When performing the circular cutting process, the software first checks the
conditions to determine whether corner processing is required,
Then the corresponding processing operation is performed according to the judgment
result.
12.A docking point
