4. Cut through the notch. Seal the opening
This function can set the graphics to turn off the fire or light in advance or delay
the fire or light, and users can customize the length of the transition\gap.
Cut off
Generally, the offset operation is mainly applied to
the outer contour and is performed on the original
lead line. As shown in the figure, the starting point
of the original lead line coincides with the
introduction line, and by offsetting outward by 20
mm, the position of the lead line has been moved
to the right, as shown on the right side of the
figure.
breach
The length of the notch can be flexibly adjusted
according to specific cutting requirements.
seal
For the gap that has been set, click "Seal" to adjust
the gap to be closed. It is equal to cancel the seal
setting
5. origin
Each part has and only one starting point, which can be set to facilitate the
addition of processes and cutting paths
Planning for the perimeter.
In the layout or drawing interface, click the "Start point" button, and then click a
position on the part outline to specify that position as the cutting starting point.
As shown in the figure below, the starting point is placed in the middle of the
