XC3000S Series Laser Cutting
System Commissioning Manual
7.6.16 Advanced option
Parameter
Default
Name
Value
DX150P
Unchecked
position loop
mode (HMI
version
greater than
5609)
Enable
Unchecked
NozzleClean
Enable Nest Checked
Docking
Unchecked
points follows
selected shape
Fix point
Unchecked
motion speed
is manual fast
(default speed:
G00)
Enable servo Unchecked
gantry axis
control
Display
Unchecked
maintenance
module
Advanced option parameters
Remarks
You can choose whether or not to search for edges before processing
in the software interface after checking the box.
The software supports nozzle cleaning after checking the box.
Supporting nesting function after checking the box.
The docking point changes with the selected drawing; unchecked,
the docking point is planned according to the entire drawing, after
checking the box.
The interface uses manual speed for all fast-positioning movements
after checking the box; unchecked for duty speed.
Checking special parts supports part of the support gantry drive
available; not recommended to arbitrarily check the box, and if you
have such requirements, please contact our after-sales professionals.
Support the maintenance function after checking the box.
92
    "
