Return origin
direction and type
Positive,
Limit
XC3000S Series Laser Cutting
System Commissioning Manual
Positive: When returning origin, move in the positive direction to
find the return to zero reference switch.
Reverse: When returning origin, move in the negative direction to
find the return to zero reference switch
Limit: Use the limit as the return origin reference switch
Return origin
speed
Back distance
Zero position: Use zero position as the return origin reference
switch
0. 12m/min Speed of finding the reference signal when returning origin
5 mm
Distance from zero return to limit signal setback
Coordinates aft
backward set as
Origin point offset
compensation
0
0 mm
Coordinate value of the reference switch in the coordinate
system
The current point as the zero point; commissioning without
limit switches for temporary commissioning
Servo axis
Not used
Fill in according to the actual configuration
Positive limit signal
Soft limit
Open
Settable positive hard limit pin
NO: no output in the untriggered state, select this item
NC: output in untriggered state, select this item
Settable negative hard limit pin
NO: no output in the untriggered state, select this item
NC: output in untriggered state, select this item
Soft limit range
Axis taq
-10~10mm The range of axis movement after the software returns origin
Current axis for labeling, detailed information notes
92
