7.6.9 Dust removal valve
Dust removal valve parameters
Parameter Name
Default Value
Remarks
Enable partition output
Row & Col
checked
4/1
Dust removal axis
DO5-DO8
Overlayed area length (XY) 20/20
Close output port delay
checked
Only open output in cutting checked
Custom removal length
1500*3000
Whether to open the dust removal function
Number of rows and columns of partitioned
dusting arrays
Which axis coordinate is used to open the dust
cylinder?
Common zone with the next dusting area, in which
this dusting and the next dusting point will be
turned on at the same time to ensure the dusting
effect
After leaving the dusting area, the dusting output is
closed with a delay to avoid frequent opening and
closing of the dusting solenoid valve when the shaft
is moving at the boundary of the area.
When checked, the dust removal points are only
output when the light is out
Distance to set up dust removal length
