XC3000S Series Laser Cutting
System Commissioning Manual
Close the power supply of all Unchecked When checked, all proportional valve power is
proportion valves after the
turned off after the processing program is rushed.
procedure.
Enable cutting head air
cooling
Unchecked
Not used
When checked, blowing is turned on when the light
comes out and off when the light stops.
Cutting head air cooling solenoid valve port setting
Air digital gas pressure alarmNot used
Settable air digital gas pressure alarm input pin
Oxygen digital gas pressure DI18
Settable oxygen digital gas pressure alarm input pin
alarm
Nitrogen digital gas pressure DI19
Settable nitrogen digital gas pressure alarm input pin
alarm
Air digital gas pressure alarm NO
logic
Oxygen digital gas pressure NO
alarm logic
Nitrogen digital gas pressure NO
alarm logic
Air analog gas pressure Not used
NO: No signal output in untriggered, select this item.
NC: signal output in untriggered, select this item
NO: No signal output in untriggered, select this item.
NC: signal output in untriggered, select this item
NO: No signal output in untriggered, select this item.
NC: signal output in untriggered, select this item
Settable air analog gas pressure feedback pin
feedback
Oxygen analog gas pressure Not used
Settable oxygen analog gas pressure feedback pin
feedback
Nitrogen analog gas pressure Not used
Settable nitrogen analog gas pressure feedback pin
feedback
Suspend processing when gas Opening
pressure alarm on
Stopping processing for gas pressure alarm
