Height sensor type
Height sensor signal port
XC3000S Series Laser Cutting
System Commissioning Manual
head
EDS On-Board Capacitive
Sensors
Not used
Select by actual heightening
equipment
Choose by actual configuration
7.6.7 Laser Device
Parameter Name
Laser Shutter
Laser Red Light
Laser Enable
Laser Reset
Shutter and Red light are
mutually exclusive.
Laser power
All outputs of PWM
Laser Alarm
Chiller Alarm
Safety door alarm
Laser Device parameters
Default Value
Remarks
DO9
Pin selection according to actual wiring
DO13
Pin selection according to actual wiring
DO4
Pin selection according to actual wiring
DO10
Pin selection according to actual wiring
unchecked
AO3
When checked, the red light button and the light gate button
are mutually exclusive and cannot be turned on at the same
time
Pin selection according to actual wiring
Check
Just check the default box
Not in use, NO Settable laser alarm pins
Alarm signal can be selected as NO or NC
Not in use, NO Chiller alarm pins can be set
Alarm signal can be selected as NO or NC
Not in use, NO Settable safety door alarm pins
Alarm signal can be selected as NO or NC
