XC3000S Series Laser Cutting
System Commissioning Manual
7.6.5 Verticality correction
Parameter Name
Start verticality
correcting
Length AB
Length AC
Length L1
Length L2
Verticality correction parameters
Default Value
Unchecked
100mm
100mm
141.4mm
141.4mm
Remarks
Turn on and off the
verticality correction
function
Verticality correction function tests the length of
one side of a cut rectangle
Perpendicularity correction function tests the
length of the other side of the cut rectangle
The length of one diagonal of the actual cut
rectangle, which needs to be measured.
After that,fill in that length here
Thelength of the other diagonal of the
rectangle
after the actual cutting, which needs to be measured.
After measuring, fill in that length here
7.6.6 Laser head
Parameter Name
Brand
Model
Focus control mode
Laser head
Default Value
RAYTOOLS
BT210/240
Manual Focusing
92
Remarks
Select the
cutting head
brand
Select the cutting head model
Choose according to the type of
focus supported by the cutting
    "
