XC3000S Series Laser Cutting
Return origin directionPositive
and type
Return to home
signal
Limit
Return origin speed 0.9
System Commissioning Manual
Absolute: Move to the zero position of the drive feedback, with the
position 0 of the drive feedback as the reference
point
Positive: When returning to zero, move in the positive direction to
find the return to zero, refer to the switch
Reverse: When returning to zero, move in the negative direction to
find the return to zero, refer to the switch
Limit: Use the limit as a return to zero reference switch
Zero position: use zero position as a return to zero reference
switch
Speed of finding the reference signal when returning to zero
Back distance
5
Distance from zero return to limit signal setback
Coordinate aft
0
backward set as
Origin point offset 0
compensation
Servo axis
axis
Coordinate value of the reference switch in the coordinate system
Use the current point as the zero point; for temporary debugging
when commissioning without limit switches
Fill in according to the actual configuration
Positive hard limit DI9
signal
NO
Negative hard limit DI7
signal
NO
Soft limit range
- 100~2
Back output
DI6
Positive and hard limit pins can be set
NO: no output for limit in untriggered state, select this item
NC: output for limit in untriggered state, select this item
Negative hard limit pins can be set
NO: no output for limit in untriggered state, select this item
NC: output for limit in untriggered state, select this item
Range of Z-axis movement of the cutting head after the software
returns to zero
Settable holding brake output pins
92
