Return origin speed
Back distance
Aft back set coordinate
Absolute zero offset
XC3000S Series Laser Cutting
System Commissioning Manual
to return to zero
1.8
Speed of finding the reference signal when returning to
zero
0
Distance from zero return to limit signal setback
0
Coordinate value of the reference switch in the coordinate
system
0
Use the current point as the zero point; commissioning
without limit switches
You can use it for temporary debugging when
7.6.4 Z-Axis follow parameter
Z-axis follow parameters
Parameter Name
Pulse number
Default
Value
10000
Remarks
Howmany pulses to send to the servo, the motor turns one revolution
Motor direction
Positive The motor rotation direction is CW or CCW; when the shaft moves in
the wrong direction, it can change this option
Pitch
10
The actual distance the shaft moves when the motor turns one
revolution
Speed unit of drive pulse/s
Selectable pulse/s, 0.1RPM, RPM
Speed loop
0.01
Default is fine
feedforward
coefficient
Max follow-up offset 30
When the absolute value of the difference between the
commanded position and the actual position is greater than this
value, the software will alarm and shut down.
Homing mode
Incremental Incremental: Find the zero signal back to zero and use the zero
signal as a reference point
92
