7.6.2 Pitch
Parameter Name
Open Pitch
Compensation
Reverse Offset
XC3000S Series Laser Cutting
System Commissioning Manual
Pitch parameters
Default
Value
Remarks
Unchecked Enable and disable the pitch compensation function for the
corresponding axis
None
Interferometer parameters are inverted, and the error is inverted
for actual conditions
7.6.3 X/Y Back origin parameter
X/Y-axis Back origin parameters
Parameter Name
Return origin mode
Default
Value
Absolute
Return origin direction and Negative
type
direction,
zero
position
Remarks
Incremental: find the zero signal back to zero and use the zero
signal as a reference point
Absolute: move to the zero position of the driver feedback,
the Position 0 of the drive feedback is the reference point
Positive: When returning to zero, move in the positive
direction
Negative: When returning to zero, move zero in the negative
direction:
Zero position: Use zero as the reference point to return to zero
Limit: determined according to the return to zero
direction, if the positive direction is selected, the positive limit
is reference point back to zero; if negative direction is
selected, the negative limit will be used as the reference point
92
