Separate set
XC3000S Series Laser Cutting
System Commissioning Manual
Selected X-axis mechanical parameters and Y-axis mechanical parameters
are not synchronized, set separately
Positive hard limit signal DI3/D16
NO
Zero signal
DI2/D15
NO
Positive and hard limit pins can be set
NO: no output for limit in untriggered state, select this item
NC: output
NC: output for limit in untriggered state, select this item
Settable zero pins
NO: no output for limit in untriggered state, select this item
NC: output for limit in untriggered state, select this item
Negative hard limit
signal
Servo axis
DI2/D14
NO
Negative hard limit pins can be set
NO: no output for limit in untriggered state, select this item
NC: output for limit in untriggered state, select this item
Fill in according to the actual configuration
Soft limit range
All limits NO
0~ 1500
Range of X-axis movement of the cutting head after the
software returns to zero
Unchecked X-axis and Y-axis limit signals are all NO
All limits NC
Unchecked All X-axis and Y-axis limit signals are NC
Separate set
Selected X-axis and Y-axis limit signals are set separately
92
    "
