XC3000S Series Laser Cutting
System Commissioning Manual
7.6 Parameter Definition
7.6.1 XY mechanical parameter and hardware config
Parameter Name
Encoder pulse number
Motor direction
Pitch
Backlash compensation
X, Y-axis mechanical parameters
Default
Value
10000
Positive
36
0
Remarks
How many pulses are sent to the servo and the motor turns one
revolution
Motor rotation direction is CW or CCW; when the shaft movesin the
wrong direction, you can change this option
The actual distance the shaft moves when the motor turns one
revolution
For compensating the backlash of the gearbox
Max speed
Max following offset
Max acceleration
Sync X parameters to Y
Sync Y parameters to X
60
60
6000
Limit the maximum speed of the machine. When the command
speed is greater than this speed, this speed is more accurate. The
maximum speed and pitch of the motor are generally used to
calculate the maximum speed
When the absolute value of the difference between the
commanded position and the actual position is greater than this
value, the software will alarm for stopping operating
The maximum value of acceleration, if any acceleration value is
greater than this value, then this value shall prevail
Unchecked Synchronize X-axis mechanical parameters to Y-axis mechanical
parameters
Unchecked Synchronize Y-axis mechanical parameters to X-axis mechanical
parameters
