XC3000S Series Laser Cutting
System Commissioning Manual
Parameter
Type
PA-101
PA-103
Fuji Servo Setting Parameters
Recommended
Value
Setting range
0
0...position 1...speed 2...torque 3...position <=>
speed
4...position <=>
Torque 5...Speed <=> Torque 6...Extended mode
7...Positioning operation
1
0...Differential input: Command pulse/symbol
1...Differential input: Forward pulse/reverse
Pulse 2... differential input :90 ° bit phase
difference 2
signal 10...open collector input
Command pulse/symbol 11... open collector input:
forward pulse/reverse pulse
12...open collector input :90° bit phase difference 2
signal
154
