2. geometric transformation
You can perform copy, mirror, rotate Angle adjustment, and
alignment operations on the current part (these functions are
especially useful for typesetting multiple inner contours).
In addition, the software provides a size measurement tool that allows
you to manually measure the size of the software.
3. Open and save
Open: directly open the CAD drawing file, or cut the
file for easy view of layout;
Save: Save the current part as nc, dxf, icd (special
format for square diamond L8200 system) file.
8、Other features
1. construction document
Under the layout interface, the software supports saving the current
incomplete layout as an inr file and can open the file again to continue the
previous layout work.
（1）Open: Open the saved project file;
（2）Save: Save the current project file;
（3）Save as: Save the current layout progress to a project file.
2. look over
The software can set the various parameters of part display when
setting up the layout;
Display number: display part number;
Display the inner contour: display the sequence
number of the inner contour of the part;
Direction arrow: indicates the cutting direction
of the part;
Display the empty move path: display the
empty move part in the current cutting path;
Display starting point: display the cutting
starting point of the part;
