frame selection needs to carry out the flight cutting of the graphics (matrix), click the
"flight cutting" button to complete the flight cutting path planning, and click the
simulation to view the actual running trajectory.
If the selected graphic does not meet the flight cutting conditions, the flight
cutting path planning cannot be completed, and the message bar will
Prompt "The current graphic cannot be cut!
Fly cut parameters
Straight cut
Start: Set the starting position of the contour
fly cutting;
Maximum connection distance: the spacing
between horizontal straight segments A and B,
as shown in the figure below:
Maximum distance deviation allowed: the
maximum vertical distance between horizontal
segments A and B, as shown in the figure
below:
Circular flying cuts
Maximum connection distance: the distance
between straight sections A and B;
